Our Mallet Enduro pedals feature our signature 4-sided clip-in mechanism surrounded by a concave platform designed to contact your shoe's outsole for improved stability and confidence. With an overall platform size sitting between our Mallet Trail and Mallet DH pedals, the Mallet Enduro is ideal for riders looking to earn their turns - a supportive feel underfoot, yet light enough for those long climbs to the top.

Features:
    • Concave platform for secure foothold
    • 6 adjustable pins per side for grip
    • Integrated traction pad technology to optimize the shoe/pedal interface
    • Ribbed body for better traction when unclipped
    • Chamfered edges to reduce rock-strikes
    • 57mm q-factor for maneuverability on tight trails
    • 4-sided entry / superior mud shedding
    • Customizable float & release angle
    • Premium bearings & double seal system
    • Owner's Manual and Technical Documents here

enduro

$199.99 USD
/
  • Add Shoes & Save 20% Using Code: MATCHBUNDLE
Color
  • In stock, ready to ship
  • Inventory on the way

Body Material 6061-T6 Aluminum

Body Dims (L x W) 94mm x 75mm

Wing Material 17-4PH Stainless

Spindle Length 57mm

Traction Pins 6 adjustable per side

Pin Length 8mm

Inner Bearing Type Igus LL-glide bearing

Outer Bearing Type Enduro MAX cartridge bearing

Endcap Hex alloy

Spindle Material Forged SCM 435 Chromoly Steel

Spring Material 300 series stainless steel

Max Rider Weight No restriction

Weight 419g per pair

Included Cleat Type 15° / 20° Standard Release, 6° Float

Cleat Notice Third-party cleats are not approved for use with Crankbrothers pedal systems. Using non-Crankbrothers cleats can reduce pedal lifespan and voids the pedal warranty.

Warranty 5 years

View our 30-Day Return Policy here

Signature 4-sided Clip-in System

Signature 4-sided Clip-in System

At the core of the Mallet Enduro lies our signature 4-sided clip-in system, which rotates independently of the pedal body to allow for unhindered entry and exit. Its open design quickly sheds mud and debris from the system, allowing for predictable performance in even the most demanding conditions.

Chamfered Edges

Chamfered Edges

Each aluminum pedal body is carefully machined at the front lower corner to allow for improved trail clearance and allow rock strikes to deflect off the pedal.

Premium Internal Components

Premium Internal Components

Tough chromoly spindles, durable Enduro® cartridge bearings, Igus® composite bearings and our Double Seal System ensure a smooth pedaling experience and enhanced longevity. The Mallet Enduro is also easily serviceable for at-home maintenance, no special tools required.

Cleats: CUSTOMIZE YOUR FLOAT & RELEASE ANGLE

Choose our new Easy Release cleats with a forgiving 10° release, or our Standard Release cleats with 15° release optimized for intermediate to advanced riders.
Continue reading

FAQ - Clip-In Pedals

All Crankbrothers clip-in pedal systems contain two pedals (one left pedal, one right pedal), one pair of cleats with mounting hardware, and one Crankbrothers icon sticker. In addition, some models of our clip-in pedals come with traction pads for customization.

Most Crankbrothers clip-in pedals come with our 6-degree float, Standard Release cleats. Our Candy 1, Eggbeater 1, and Double Shot 1 pedals come with our Easy Release cleats instead, with a smaller release angle required to unclip but still featuring 6 degrees of float.

Although closely related, float and release angle refer to separate characteristics of our cleats. "Float" is what we call the amount of rotational free play while clipped-in, whereas "Release Angle" refers to the angle of rotation of the cleat required to completely exit from the pedal, ie "unclip".

All standard bicycle pedal spindles are threaded specifically for either the left or right side of your bike, ours included - it's important to double check you're installing the correct pedal to the matching crank arm to avoid damage. A close inspection of the flange of the pedal spindle will indicate either Left side (with a grooved flange) or Right side (with a flat flange).

You'll need an 8mm hex wrench and bike grease for proper installation of your pedals - watch our tutorial here!

Maintenance schedules can vary greatly depending on riding conditions and mileage, but as a general rule of thumb, we recommend a seasonal re-grease of the internal components to keep things running smoothly. We also offer refresh kits with new bearings, seals, and hardware when a full overhaul is desired. Pro tip: Avoid using a pressure washer at close distances to clean your pedals, as water could get past the external seals and displace the grease your pedals need to spin freely.

No - SPD cleats won't work with our pedals.

Although we always recommend using Crankbrothers shoes featuring MATCH Technology for an optimized setup right out of the box, any MTB or Gravel shoes which feature a recessed two-hole cleat mounting box are compatible with our pedal system. With third-party footwear, it may be necessary to use additional shims or traction pads to fine-tune the shoe-to-pedal interface [pro tip: use our Cleat Tool to find your ideal shim setup]. In addition, you can even adapt a three-hole road shoe to be compatible with our Eggbeater or Candy pedals with the use of our adapter kit.
