Mallet DH Clip-In Pedals - SuperBruni Edition
SKU: 16248
The Choice Of DH World Champions.
Our Mallet DH pedals feature our signature 4-sided clip-in mechanism surrounded by a concave platform designed to contact your shoe's outsole for improved stability and confidence. With our largest platform size offered (13% more surface area than Mallet Enduro), the Mallet DH is ideal for gravity racers and riders looking for the security and confidence of being clipped-in through the rowdiest sections of the track, combined with the ultimate support underfoot previously only found in flat pedals.
- Designed with 5x World Champion Loic Bruni
- Asymmetrical double-anodized red & blue colorway
- Concave platform for secure foothold
- 8 adjustable pins per side for grip
- Traction pad technology customizable interface
- Ribbed body for better traction when unclipped
- Chamfered edges to reduce rock-strikes
- 57mm q-factor for stability at speed
- 4-sided entry / superior mud shedding
- Customizable float & release angle
- Premium bearing & double seal system
- Owners Manual and Technical Documents here
downhill
- Add Shoes & Save 20% Using Code: MATCHBUNDLE
Body Material 6061-T6 Aluminum
Body Dims (L x W) 100mm x 78mm
Wing Material 17-4PH Stainless
Spindle Length 57mm
Traction Pins 8 adjustable per side
Pin Length 8mm
Inner Bearing Type Igus LL-glide bearing
Outer Bearing Type Enduro MAX cartridge bearing
Endcap Hex alloy
Spindle Material Forged SCM 435 Chromoly Steel
Spring Material 300 series stainless steel
Max Rider Weight No restriction
Weight 479g per pair
Included Cleat Type 15° / 20° Standard Release, 6° Float
Cleat Notice Third-party cleats are not approved for use with Crankbrothers pedal systems. Using non-Crankbrothers cleats can reduce pedal lifespan and voids the pedal warranty.
Warranty 5 years
